FreeStyle Mini LED has five menu options. With white menu, the Kelvin range is from 2700K to 6500K with Dimming, Kelvin and Green/Magenta control channels. In the first color menu, Kelvin range is from 2500K to 9900K, with three additional channels, Gel, Hue Angle and Saturation. The Gel channel includes Kino Flo presets such as blue & green screen and over 100 well-known lighting gels. The second color menu provides individual RGB (red, green, blue) control. The CIE xy menu allows you to enter xy coordinates. The FX (Effects) menu has custom presets like Candle, Fire, TV, Police, Lightning, Paparazzi, Pulse and Scroll. The controller comes with standard DMX, wireless DMX (Lumen Radio®), universal voltage input 100-240VAC and 24VDC.
|
Contents
1 FreeStyle Mini LED Fixture 1 FreeStyle 120 LED DMX Controller 1 MTP-BG41 Mount w/ Baby Receiver Short (16mm) 1 Extension, 25ft 1 Soft Case |
(CFX-F10) (LED-120X)
(MTP-BG41S)
(X08-F125) (BAG-FS102) |
|
Dimensions 19 x 11 x 13.5” (48 x 28 x 34cm)
Weight 16 lb (7kg)
|
|
