Kramer CRS-PlugNView-H Active Optical Armored 4K HDMI Cable

Kramer CRS-PlugNView-H Active Optical Armored 4K HDMI Cable

Regular price $383.20 CAD
Regular price Sale price $383.20 CAD
Sale Sold out

SKU:CRS–PlugNView–H–33

Length

All efforts are made to ensure accuracy of stock info on site. There may be delays in updates due to "over the counter sales" during the day.  For most accurate info, please contact us at 416-251-1571 or sales@hdsource.ca

Kramer CRS-PlugNView-H Active Optical Armored 4K HDMI Cable

For full product specifications in PDF format, please click HERE

Detailed Specifications


Video:
Video Resolution: Up to 4K 60Hz 4:4:4 (3840x2160 & 4096x2160)

Data Rate: Up to 18 Gbps

Supported color spaces: RGB, YCbCr, xvYCC, Adobe sRGB, sYCC601, BT.2020

HDMI Support: HDCP 2.2, HDR–10, HLG, Dolby Vision™, EDID and CEC

Audio: Supported audio formats: Dolby® Digital Plus, Dolby® TrueHD, DTS–HD Master Audio®, DVD Audio, SA–CD

PHYSICAL:
Connector-1 (source end): Male HDMI Type A, 24K gold–plated
Connector-1 (display end): Male HDMI Type A, 24K gold–plated
HDMI Connector Dimensions: 27.8″x 0.78″x 0.38″ (70.7mm x 20mm x 9.8mm)
Cable Structure: Hybrid Optical Fiber Cable
Fiber Optic: 50/125u OM3 fiber
Armor Material: Kevlar® and stainless steel
Long term crush resistance: 1000N (100 kg, 225lbs)
Short term crush resistance: 2000N (204 kg, 450lbs)
Bending radius: 10 D (Dynamic) / 20 D (Static)
Long term tensile strength test: 400N (41 kg, 90lbs)
Short term tensile strength test: 800N (81 kg, 180lbs)

JACKET:
Material: TPU (thermoplastic polyurethane) — LSHF
Color: Black
Diameter: 5.8mm

Power:
Source: No external power supply is needed (draws current from the video source)

Environmental Conditions:
Operating Temperature: +32~+122˚F (0~+50˚C)
Storage Temperature: –40~+158˚F (–40~+70˚C)
Operating Humidity: 10 ~ 80%

REGULATORY:
Environmental: CE, FCC
Safety: RoHS 2011/65/ EU

Product Dimensions:
24.00cm x 20.00cm x 32.00cm (9.45" x 7.87" x 12.60" ) W, D, H

Product Weight:
5.2kg (11.5lbs) approx.
