NBX-2TX-12G-LC

Transmitter or Receiver

NBX-2RX-12G-LC

12G/HD/SD-SDI Dual Fiber Optic Receiver LC Connectors

The NBX-2RX-12G-LC from MultiDyne provides a miniature solution to receive two 12G/HD/SD-SDI signals over single-mode fiber optic cable using LC connectors at distances up to 10km.

The NBX-2RX-12G-LC provides two SDI fiber optic inputs on LC connectors with a wavelength range of 1270 nm to 1610 nm and offers one output to each SDI signal on a 75 Ohm BNC connector.

The NBX-2RX-12G-LC provides reclocking on both of the outgoing SDI signals on the BNC connectors.  Dual Color LED indicators to provide a GREEN status indication to show that the reclockers are locked to valid SDI signals or a RED status indication to show a valid SDI signal is not present.

Power to the NBX-2RX-12G-LC is provided by an external AC adapter with a locking DC connector supplied with the module.

Features

  • Excellent Value
  • Compact Size
  • Rugged Steel Enclosure
  • Highest of Quality Components


Applications

  • Live Broadcast
  • Arenas and Stadiums
  • Shared Control Rooms
  • Campus Facilities

NBX-2TX-12G-LC


12G/HD/SD-SDI Dual Fiber Optic Transmitter LC Connectors

The NBX-2TX-12G-LC from MultiDyne provides a miniature solution to transmit two 12G/HD/SD-SDI signals over single-mode fiber optic cable using LC connectors at distances up to 10km.

The unit accepts two SDI signals on 75 Ohm BNC connectors and provides one optical output of each signal on an LC fiber optic connector over single-mode fiber optic cable with a 1310 nm wavelength.

The NBX-2TX-12G-LC provides reclocking on both of the incoming SDI signals on the BNC connectors. Dual-color LED indicators to provide a GREEN status indication to show that the reclockers are locked to valid SDI signals or a RED status indication to show valid SDI signals are not present at the inputs.

Power to the NBX-2TX-12G-LC is provided by an external AC adapter with a locking DC connector supplied with the module.

Features

  • Excellent Value
  • Compact Size
  • Rugged Steel Enclosure
  • Highest of Quality Components

Applications

  • Live Broadcast
  • Arenas and Stadiums
  • Shared Control Rooms
  • Campus Facilities
