SmallHD Indie 7 Monitor

Name: SmallHD Indie 7 Monitor
Brand: SmallHD
SKU: MON-INDIE-7
Price: 2049.00 CAD
Availability: InStock

$2,049.00 CAD

Sale Sold out

SKU:MON-INDIE-7

Quantity

All efforts are made to ensure accuracy of stock info on site. There may be delays in updates due to "over the counter sales" during the day. For most accurate info, please contact us at 416-251-1571 or sales@hdsource.ca

SmallHD 7 inch Smart Monitor (MON-INDIE-7) with daylight Visibility

Featuring a user-customizable touchscreen UI powered by PageOS 4 software, compatible with optional Camera Control for RED® DSMC2® & KOMODO™

Model: MON-INDIE-7
Display: 7-inch touchscreen, 1920x1200, 323 PPI
Input: SDI, HDMI, Micro USB
Output: SDI, HDMI 2.0 , ⅛” Headphone Jack, Camera Control
Power Input: 2mm barrel connector (DC 10-34v),Sony L-Series dual battery bracket

Detailed Specifications

SKU:
MON-INDIE-7

Product ID:
5182721785989

Item Weight (oz):
18.9

Package Weight (oz):
26

Height (in):
4.67

Width (in):
1.32

Length/Depth (in):
7.09

Compliance:
FCC, IC, CE, RoHS

Operating Temperature:
30F to 100F

Storage Temperature:
0F to 120F

Mount Points:
Four ¼-20 Mount Points (Left, Right, Bottom, and Back)

Construction:
Anodized aluminum chassis

Panel Type:
IPS LCD Touchscreen

Diagonal Size:
7.02

Resolution:
1920x1200

Pixel Density:
323

Aspect Ratio:
16:9

Active Area:
5.95 x 3.72

Max Brightness:
1000 Nits

Contrast:
1000:1

Color Depth:
10-bit Processing (8-bit panel)

Viewing Angle:
160

Backlight Type:
LED

Adjustable Backlight:
Yes

Refresh Rate:
Synchronizes with input from 48Hz to 60Hz

Input Signal:
3G-SDI Input Types:
YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100

HD-SDI Input Types:
YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98

SD-SDI Input Types:
YCC 4:2:2 @ 10-bits: 480i59.94, 576i50

HDMI Input Types:
YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4: 3840x2160 30p, 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76,
