Approx. 3.6 kg (body only without lens, VF, Mic)
Approx. 7 lb 15 oz (body only without lens, VF, Mic)
Dimensions (W x H x D) *1
150 x 269 x 332 mm (excluding protrusions, body only)
6 x 10 5/8 x 13 1/8 inches (excluding protrusions, body only)
Power Requirements
DC 12 V (11 V to 17.0 V)
Power Consumption
Approx. 22 W (while XAVC recording, color LCD on)
Approx. 24 W (while XAVC recording, CBK-VF02 viewfinder and color LCD on)
Operating Temperature
0° C to 40° C
32° F to 104° F
Storage Temperature
-20°C to +60°C
-4°F to +140°F
Continuous Operating Time
Approx. 200 min with BP-L80S,
Approx. 240 min with BP-GL95A
Recording Format (Video)
XAVC Intra:
XAVC-I mode:
MPEG-4 AVC/H.264, CBG, Max.112 Mbps
XAVC Long:
XAVC-L 50 Mode:
MPEG-4 AVC/H.264, VBR, Max. 50 Mbps
XAVC-L 35 Mode:
MPEG-4 AVC/H.264, VBR, Max. 35 Mbps
XAVC-L 25 Mode:
MPEG-4 AVC/H.264, VBR, Max. 25 Mbps
MPEG HD422:
HD422 mode: MPEG-2 422P@HL, CBR, Max.50 Mbps
MPEG HD:
HQ mode: MPEG-2 MP@HL, VBR, Max.35 Mbps
MPEG IMX: *2
MPEG-2 422@ML, CBR, 50 Mbps
DVCAM:
CBR, 25 Mbps
Recording Format (Audio)
XAVC Intra: LPCM 24 bits, 48 kHz, 4 channels
XAVC Long: LPCM 24 bits, 48 kHz, 4 channels
MPEG HD422: LPCM 24 bits, 48 kHz, 4 channels
MPEG HD: LPCM 16 bits, 48 kHz, 4 channels
MPEG IMX: LPCM 16/24 bits, 48 kHz, 4 channels *2
DVCAM: LPCM 16 bits, 48 kHz, 4 channels
Recording Format (Proxy Video)
XAVC Proxy: AVC/H.264 Main Profile 4:2:0 Long GOP, VBR
1280 × 720, 9 Mbps (Target Rate)
1280 × 720, 6 Mbps (Target Rate)
640 × 360, 3 Mbps (Target Rate)
480 × 270, 1 Mbps, 500 kbps (Target Rate)
Recording Format (Proxy Audio)
XAVC Proxy: AAC-LC, 128 kbps, 2 channels
Recording/Playback Time (XAVC Intra, XAVC Long) *2
XAVC-I mode:
Approx. 120 min. with 128 GB SxS card
Approx. 60 min. with 64 GB SxS card
Approx. 30 min. with 32 GB SxS card
XAVC-L 50 mode:
Approx. 240 min. with 128 GB SxS card
Approx. 120 min. with 64 GB SxS card
Approx. 60 min. with 32 GB SxS card
XAVC-L 35 mode:
Approx. 340 min. with 128 GB SxS card
Approx. 170 min. with 64 GB SxS card
Approx. 85 min. with 32 GB SxS card
XAVC-L 25 mode:
Approx. 440 min. with 128 GB SxS card
Approx. 220 min. with 64 GB SxS card
Approx. 110 min. with 32 GB SxS card
Recording/Playback Time (MPEG-2 HD422/HD420) *2
MPEG HD422 mode:
Approx. 240 min. with 128 GB SxS card
Approx. 120 min. with 64 GB SxS card
Approx. 60 min. with 32 GB SxS card
MPEG HD420 HQ mode:
Approx. 360 min. with 128 GB SxS card
Approx. 180 min. with 64 GB SxS card
Approx. 90 min. with 32 GB SxS card
Recording/Playback Time (MPEG IMX 50M) *2
Approx. 240 min. with 128 GB SxS card*2
Approx. 120 min. with 64 GB SxS card
Approx. 60 min. with 32 GB SxS card
Recording/Playback Time (DVCAM) *2
Approx. 440 min. with 128 GB SxS card
Approx. 220 min. with 64 GB SxS card
Approx. 110 min. with 32 GB SxS card
Recording Frame Rate
XAVC Intra (XAVC-I mode):
1920 × 1080: 59.94i, 50i, 29.97p, 25p, 23.98p
1280 × 720: 59.94p, 50p
XAVC Long (XAVC-L 50 mode):
1920 × 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 23.98p
1280 × 720: 59.94p, 50p
XAVC Long (XAVC-L 35 mode):
1920 × 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 23.98p
Recording Frame Rate
XAVC Long (XAVC-L 25 mode):
1920 × 1080: 59.94i, 50i
MPEG HD422:
1920 × 1080: 59.94i, 50i, 29.97p, 25p, 23.98p
1280 × 720: 59.94p, 50p, 29.97p, 25p, 23.98p
MPEG HD420:
1920 × 1080: 59.94i, 50i, 29.97p, 25p, 23.98p
1440 × 1080: 59.94i, 50i
1280 × 720: 59.94p, 50p
MPEG IMX: *2
720 × 486: 59.94i
720 × 576: 50i
DVCAM:
720 × 480: 59.94i
720 × 576: 50i
